Mac Afric BV20BL - Machine Illustration - Controls and Details; Slide Control Illustrations (Figure 3); Tailstock and Gear Controls (Figure 4 & 5)

9
Fig. 3
Tool Post locking handle Compound slide compound slide control
Saddle control Traverse slide control Auto-feed lever Traverse slide
Fig 4 Tailstock barrel lock
Tailstock barrel Tailstock drive handle
Tailstock clamping Tailstock offset screw
Fig 5 Gear change levers ( B ) ( A )
Reversing switch (under cover)
Machine Illustration and key parts description
