Page No.
General Instruction 2
Assembly Instruction 3
Machine Specification / Definitions 4
Identification and Description of the Parts 5
Machine Illustration and parts Description 8
Identification and Description of the Parts 10
Machine Illustration and parts Description 11
Bench Lathe Maintenance 12
Oil Lubrication Points 13
Parts Diagram 14
A 15
B 17
C 19
D 21
E 23
F 25
G 27
H 29
Good Working Practices Safety
The following suggestions will enable you to observe good working practices, keep yourself
and fellow workers safe and maintain tour tools and equipment in good working order.
WARNING!
KEEP TOOLS AND EQUIPMENT OUT OFTHE REACH OF YOUNG CHILDREN
BENCH LATHE
Primary precautions
These machines are supplied with a mould 13 Arnp. Plug and 3 core power cable. Before
using the machine inspect the cable and the plug to make sure that neither are damaged. If
any damage is visible have the machine inspected / repaired by a suitably qualified person. If
it is necessary to replace the plug, it is preferable to use an ‘unbreakable’ type that will resist
damage. Only use a 13 Arnp. If extension leads are to be used, carry out the same safety
checks on them, and ensure that they are correctly rated to safely supply the current that is
required for your machine. Idealy, your lathe should be installed close to a correctly rated
power supply, in a warm dry environment, well ventilated and illuminated by bright clear
natural light, with adequate access all around the machine, and sufficient adjacent storage
space for your tools, accessories and material.
