Fig 2
Tailstock barrel Clamping lever Chuck assembly
Fig. 3
Tool Post locking handle Compound slide compound slide control
Saddle control Traverse slide control Auto-feed lever Traverse slide
Fig 4 Tailstock barrel lock
Tailstock barrel Tailstock drive handle
Tailstock clamping Tailstock offset screw
Machine Illustration and key parts description
