4. Open the deector guard (15) and hold it in position (Fig. 7, step 1).
5. Carry the grass catcher (8) by its carry handle (8a).
6. Align the support with the hooks (18a) and hang the grass catcher onto it (Fig.
7, step 2).
7. Carefully release the deector guard (15) afterwards.
Grass catcher
1. Clip the three rubber clips (8c) to the supporting rod (8d) of the grass catcher (8)
(Fig. 5).
2. The carry handle (8a) is already preassembled on the top cover (8b) and its
position is rotatable to t the intended use (Fig. 6).
3. The grass catcher (8) is ready for use.
WARNING!
Make sure the clamp levers (6) are properly tightened
before using the product.
WARNING!
Do not attempt to use the product without the grass catcher
attached – danger of ying objects! The motor must be switched off
and the blade must have stopped rotating before you remove the grass
catcher. The grass catcher must be fully assembled with the top part,
bottom part and collection tongue all in position before rst use.
Before you start
Assembly
8c
8d
Fig. 5
8a
8b
Fig. 6
