What to do if MAC TOOLS MW135 has no weld output, wire does not feed, and the fan does not run?
First, ensure the power cord is securely plugged into the receptacle. Then, check the building line fuse and replace it or reset the circuit breaker if it's open. Make sure the power switch is in the On position. Finally, for CSA models, check the circuit breaker CB and reset it if needed.
Why is there low weld output on my MAC TOOLS Welding System?
The low weld output might be caused by incorrect input voltage. Connect the unit to the proper input voltage or check for low line voltage. Also, ensure the voltage switch is in the desired position.
What to do if MAC TOOLS MW135 Welding System electrode wire feeding stops during welding?
If the electrode wire feeding stops during welding, try the following: * Straighten the gun cable or replace any damaged parts. * Adjust the drive roll pressure. * Change to the proper drive roll groove. * Readjust the hub tension. * Replace the contact tip if it is blocked. * Clean or replace the wire inlet guide or liner if it is dirty or plugged. * Replace the drive roll or pressure bearing if it is worn or slipping. * Secure the gun trigger leads or repair them. * Check the circuit breaker CB or CB2 and reset if necessary. * Check and clear any restrictions at the drive assembly and liner.
What to do if MAC TOOLS MW135 has no weld output but wire feeds?
If there is no weld output but the wire feeds, ensure the work clamp has good metal-to-metal contact. Replace the contact tip. Also, check for proper polarity connections.
General| Brand | MAC TOOLS |
|---|---|
| Model | MW135 |
| Category | Welding System |
| Language | English |
Explains the meaning and application of various warning symbols used in the manual.
Details critical hazards like electric shock, arc rays, fire, explosion, gases, hot parts, and magnetic fields associated with arc welding.
Covers additional symbols for installation/operation and lists principal safety standards.
Discusses electromagnetic fields, their potential effects, and mitigation strategies.
Lists technical specifications for 120 VAC and 230 VAC models, including output, input, and dimensions.
Explains duty cycle percentages and indicators of overheating for the welding unit.
Illustrates the minimum and maximum voltage and amperage output capabilities of the welding power source.
Instructions for installing the welding gun, changing polarity, and setting up the gas supply.
Covers installing the wire spool, adjusting hub tension, and connecting input power for 120/230V models.
Step-by-step guide for feeding welding wire through the machine and gun assembly.
Explains the function of each control knob and switch on the welding unit.
Provides recommended weld parameters (wire size, gas, voltage, speed) for various materials and applications.
Outlines scheduled maintenance tasks and explains the unit's overload protection system.
Details procedures for changing drive rolls, wire guides, contact tips, and gun liners.
A table listing common welding problems and their corresponding solutions and remedies.
Provides detailed electrical circuit diagrams for the 120 VAC and 120 VAC CSA models.
Offers a detailed electrical circuit diagram for the 230 VAC model.
Illustrates typical MIG process connections and lists common shielding gases and their applications.
Guides on setting parameters, gun positioning, movement, bead characteristics, and weld quality.
Covers common weld defects like spatter, porosity, penetration, fusion, burn-through, waviness, and distortion with solutions.
Lists all components and part numbers for the main welding machine assembly.
Details the available optional drive rolls and their compatible wire diameters.
Lists all components and part numbers for the GA16C2 welding gun.
