PressSystem 620080020 Rev07 062018.doc
11
Figura 1
Di seguito schema d’esempio di un tipico
impianto con pompa di superficie:
Example of a typical system with surface
pump:
X
NO
Valvola di
ritegno
obbligatoria
Check valve
required
