Form # 46584 Issue 11/06 Web Rev_01
142
ASSEMBLY
Preparing 962/963 Harvest Header
for Windrower Tractor (continued)
5. Attach reel lift hose and coupler (supplied in
adapter kit) as follows:
30'
: Attach to hydraulic line (F) at header left
leg.
36': Attach to hose (G) at header left leg.
ATTACH REEL LIFT HOSE – 962/963 HEADER
