M150/M200 QUICK CARD
Form 169414 Rev. A Page 4 of 4
Supplement to M150/M200 Operator’s Manual. See manual for greater detail.
Operator Station Features
Header Index Mode (D-Series Headers Only):
Enhanced reel/draper speed controls may be desirable in variable crop and terrain conditions.
Allows the reel or reel and drapers to be driven by reference to operator ground speed, so that header systems will speed up and slow
down as ground speed changes.
Operation of Header Index for REEL SPEED:
1. With all bystanders clear, start windrower, and engage the header.
2. While stationary, with the GSL in Park, use the reel speed control to set a ‘Minimum Reel Speed’.
3. When operating at grounds speeds faster than the minimum reel speed + header index value, CDM reel speed view will change
to ‘Reel Index’. Using the reel speed control, index value can be adjusted.
4. Reel speed will be equal to the greater of ‘ground speed + index value’ or ‘minimum reel speed’.
Operation of Header Index for DRAPER SPEED:
Follow instructions above, using the CDM’s Draper/Auger speed control button rather than the GSL’s Reel speed control.
Return to cut:
The Return-to-Cut feature enables the operator to have the header return to a preselected cutting height and angle. CDM’s Tractor Setup
allows ‘RTC’ to be set to ‘Height Only’ or ‘Height & Tilt control’.
To set, with engine running, engage the header. Use GSL controls to move header to cutting position. Press ‘Return To Cut’ (green light
illuminates). Until ‘RTC’ is turned off, this header position will remain in memory as cutting height/angle.
Single-touch of ‘Header Down’ returns the height. Double-tap of either angle button returns Header Angle.
Floatation Presets:
A-Series, R-Series, or D-Series w/o hydraulic deck shift
Float preset/deck shift switch allows for auto-memory of 3 different floatation trim cylinder positions.
i.e. #1 - Border w lh 5.0, rh 6.5
#2 - Normal w lh 5.0, rh 5.0
#3 – Rocky w lh 6.5, rh 6.5
D-Series with Hydraulic Deck Shift
Deck Shift switch will activate hydraulic deck shifting when header is engaged, and allows for auto-memory of trim cylinder adjustments in
each delivery opening position. Allows for compensation of weight shifts to the floatation springs.
SUGGESTED CDM OVERLOAD SETTINGS
TRACTOR
MODEL
HEADER
MODEL
KNIFE/DISC OVERLOAD
SPEED (spm/rpm)
PRESSUE
SENSOR
APPLICATION
PRESSURE
OVERLOAD
SETTING
TRACTOR’S
PRESSURE
SETTING
M150 D60 / A40D 75% of set knife speed (spm) reel / draper 3000psi 3200psi
M150 D60 / A40D 75% of set knife speed (spm) knife/conditioner 4000psi 4200psi
M150 R80 1300 disc rpm disc pressure 4000psi 4200psi
M200 R80 1300 disc rpm disc pressure 4300psi 4500psi
M200 D60 / A40D 75% of set knife speed (spm) reel / draper 3000psi 3200psi
M200 D60 / A40D 75% of set knife speed (spm) knife/conditioner 4300psi 4500psi
