O F 8 P A G E S
CFX Series
MIXERS
CFX Series
CFX SERIES 12-, 16-, and
20-Channel Mic/Line Mixers
CFX Series
O F 8 P A G E S
MIXERS
CFX SERIES
CFX SERIES 12-, 16-, and
20-Channel Mic/Line Mixers
CFX
™
Series
CFX SERIES 12-, 16-, and 20-Channel Mic/Line Mixers
1
O F 8 P A G E S
MIXERS
CFX Series
O F 8 P A G E S
CFX Series
MIXERS
CFX Series
CFX SERIES 12-, 16-, and
20-Channel Mic/Line Mixers
2
Specications
Frequency Response:
32 Hz to 20 kHz +0, –1 dB
Distortion:
THD and SMPTE IMD; 20 Hz to 20 kHz
Mic Input to Main Output < 0.05% @ +4 dBu output
Noise:
20 Hz to 20 kHz (150 Ohms source impedance)
Equivalent Input Noise (EIN) –127 dBU
Residual Output Noise Main, Monitor, & Effects outputs
Channel & Master levels off –95 dBU
Common Mode Rejection Ratio (CMRR):
@1 kHz, Trim @ 0 dB 60 dB
Crosstalk:
Adjacent Inputs or Input to Output –90 dB @ 1 kHz
Fader Off –90 dB @ 1 kHz
Mute Switch and Break Switch Mute –80 dB @ 1 kHz
Input Level Trim Control Range:
+6 to –50 dB
Phantom Power:
+48 VDC
Equalization
Low Cut: 100 Hz, –18 dB/octave
Mono Channel EQ:
High +15 dB @ 12 kHz
Mid +15 dB @ 100 Hz to 8 kHz
Low +15 dB @ 80 Hz
Stereo Channel EQ:
High +15 dB @ 12 kHz
High Mid +15 dB @ 100 Hz to 3 kHz
Low Mid +15 dB @ 400 Hz
Low +15 dB @ 80 Hz
Graphic EQ:
(9 bands): +15 dB, Q=1.414 ISO octave centers @ 63 Hz,
125 Hz, 250 Hz, 500 Hz, 1k,
2k, 4k, 8k, 16 kHz
Mixer Rated Output:
Main, Sub, Aux, & EFX +4 dBU
Maximum Rated Output +20 dBU
Maximum Input Levels:
Mic input, trim @ +6 dB +18 dBu
Line input, trim @ –15 dB +38 dBu
Insert Return, Stereo Line Input,
Tape Input, and Effects Return +20 dBu
Maximum Voltage Gain:
Mic Input to
Insert Output 50 dB
Tape Output 66 dB
Sub Output 66 dB
Main Output 76 dB
Aux Send 71 dB
Line Input to
Insert Output 30 dB
Tape Output 46 dB
Sub Output 46 dB
Main Output 56 dB
Aux Send 51 dB
Stereo Line Input to
Tape Output 40 dB
Sub Output 40 dB
Main Output 50 dB
Aux Send 45 dB
Tape Input to
Main Output 30 dB
Effects Return to
Main Output 30 dB
Input Impedance
Mic Input: 3 kΩ, balanced
Line Input: 40 kΩ, balanced
Insert Return, Stereo Line Input,
Tape Input, and Effects Returns: 10 kΩ, unbalanced
Output Impedance
Main Output, Insert Output, Tape Output,
Sub Output, and Effects Sends: 150 Ω
Digital Effects
Resolution:
32-bit EMAC processing, 2-channel
Number of Presets:
16
Parameters:
2 controllable
Channel Level Set LED (Sensitivity):
0 dBu (normal operating level)
VU Meters
Main L/R
12 Segments: Clip, +10, +7, +4, +2, 0, –2, –4, –7,
–10, –20, –30
Physical Dimensions:
CFX•12
Height 4.6" (117 mm)
Width 17.2" (437 mm)
Depth 15.7" (399 mm)
Overall Depth 5.0" (127 mm)
Weight 17.8 lbs. (8.1 kg)
CFX•16
Height 4.6" (117 mm)
Width 21.4" (544 mm)
Depth 15.7" (399 mm)
Overall Depth 5.0" (127 mm)
Weight 21.0 lbs. (9.5 kg)
CFX•20
Height 4.6" (117 mm)
Width 25.6" (650 mm)
Depth 15.7" (399 mm)
Overall Depth 5.0" (127 mm)
Weight 24.3 lbs. (11.0 kg)
www.mackie.com
16220 Wood-Red Road NE, Woodinville, WA 98072 USA
888.337.7404, fax 425.487.4337, sales@mackie.com
UK +44.1268.571.212, fax +44.1268.570.809, uk@mackie.com
ITALY +39.0522.354.111, fax +39.0522.926.208, italy@mackie.com
FRANCE +33.3.85.46.91.60, fax +33.3.85.46.91.61, france@mackie.com
GERMANY +49.2572.96042.0, fax +49.2572.96042.10, germany@mackie.com
