Mackie CFX20 - Effects Board Schematics; Effects Board Schematics and PCB Layouts

A-4
080-088-00 IC, ADSP-2163 U2
140-009-00 RESISTOR TF SMT 2.2 5% R11
140-049-00 RES TF SM .1W 5% 100 OHM 100 5% R33-34
140-053-00 RESISTOR TF SMT 150 5% R13-14
140-073-00 RESISTOR TF SMT 1K0 5% R4 R8-9 R20 R31
140-089-00 RESISTOR TF SMT 4K7 5% R19 R21 R23-30
140-097-00 RESISTOR TF SMT 10K 5% R7 R10 R32
140-097-00 RESISTOR TF SMT *DO NOT STUFF* 10K 5% R16-18 R15
140-114-00 RESISTOR TF SMT 47K 5% R3 R5-6 R22
140-123-00 RESISTOR TF SMT 100K 5% R2 R12
140-123-00 RES TF SM .1W 5% 100K OHM 100K 5% R35
140-139-00 RESISTOR TF SMT 470K 5% R1
212-001-00 CAPACITOR CERAMIC SMT 0.01 10% C30-31
212-003-00 CER 100PF 5% 50V NPO SM 100PF 5% C46 C49
212-005-00 CAPACITOR CERAMIC SMT 20PF 5% C2 C6
212-007-00 CAPACITOR CERAMIC SMT 0.047 5% C18
212-016-00 CER 1000PF 5% 5OV NPO SM 1000PF 5% C42-45 C47-48 C50-56
212-023-00 CAPACITOR CERAMIC SMT 0.001 10% C7-8 C36
212-024-00 CER 1UF 25V Y5V 1206 1UF -400 C10-11 C15 C34
212-027-00 CAPACITOR CERAMIC SMT .1UF 10% C1 C3-4 C12 C14 C16-17 C20 C24-25 C27
C29 C32-33 C38
212-029-00 CAPACITOR CERAMIC SMT 270PF 5% C22-23
212-032-00 CAPACITOR CERAMIC X7R SMT 2200PF 10% C35 C37 C39-41
220-011-00 LYT 100UF 20% 25V RAD 100UF 10% C5
223-003-00 LYT 22UF 20% 6.3V SM 22UF 20% C9
223-004-00 LYT 10UF 20% 16V SM 10UF 20% C13 C19 C21 C26 C28
300-003-00 DIODE SIGNAL SMD DL4148 D1-4
315-017-00 CRYSTAL, 24.576 MHZ 24.576 Y1
325-027-03 IC, SMD, DUAL D F/F 74HC74A U6
325-071-03 IC, HEX, INV, SMD 74HCU04 U1
329-042-03 IC, AD1819 QFP AD1819 U3
329-047-03 IC, 32KX8 SRAM 20nS 7C256-20 U4-5
400-280-00 HDR, SKT, 16P, .1X1 STR 1.75 J1
450-192-00 PCB, LC EFFECTS Z1
601-009-00 FERRITE BEAD, SMT Z=1000 FB1-3
601-010-00 FERRITE SMT POWER Z=73 FB5
055-192-00 REV B, Effects board
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
192b
