A-5
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
040-137-00 CBL ASSY, 18GA 1010 GRN/YEL 9” E2
LUG/AMP IN
130-002-02 POT RTY 50KB 9MM MNO H TN 50KB R47 R55 R59 R126 R135 R139 R209 R220
R224 R285 R294 R298
130-003-02 POTRTY 50KG 9MM MN TN PAN 50KG R32-33 R38-39 R63 R112-113 R118-119
R143 R195-196 R201-202 R228 R273-274
R279-280 R304 R332-333 R340-341 R387
R429-430 R438-439 R492 R525-526 R531
R535 R617 R621
130-022-02 RESISTOR POT 9MM HORIZ 10KB R545 R629
130-030-02 RESISTOR POT 9MM HORIZ 5KZY R15 R95 R180 R260
130-031-00 POT SLD 10KD 60MM MONO 10KD R74 R154 R239 R316 R562 R569 R648 R713
130-032-00 POT SLD 50KD 60MM DUAL 50KD R398 R503 R861
130-061-02 POT 50KG 12MM DUAL WO SLV 50KG R320 R350 R360-361 R374 R417 R450
R464-465 R481 R539 R744 R748 R753 R759
130-064-02 POT 500KC 12MM DUL WO SLV 500KC R56 R136 R221 R295
130-075-00 POT SLD 50KW 30MM PANA 50KW R603 R605 R664-665 R669 R729 R732 R735
R825
140-032-00 RESISTOR CF 20 5% R848
140-037-00 RESISTOR CF 33 5% R847
140-049-00 RESISTOR TF SMT 100 5% R624
140-051-00 RES TF SM .1W 5% 120 OHM 120 5% R407 R409 R412 R415 R514 R516 R576
R578 R652 R654 R786 R790 R846
140-057-00 RESISTOR CF 220 5% R852-853 R857-860
140-061-00 RESISTOR CF 330 5% R842 R844
140-064-00 RES TF SM .1W 5% 430 OHM 430 5% R765
140-065-00 RESISTOR CF 470 5% R841 R843 R845
140-066-00 RES TF SM .1W 5% 510 OHM 510 5% R35 R37 R40-41 R70-73 R115 R117 R121
R132 R150-153 R198 R200 R204 R215
R235-238 R276 R278 R282 R291 R312-315
R336-337 R347 R356 R394-397 R433-434
R445 R456 R499-502 R618 R675 R840
R850-851
140-068-00 RESISTOR CF 620 5% R839
140-073-00 RES TF SM .1W 5% 1K0 OHM 1K0 5% R10 R13 R53-54 R60 R62 R85 R88 R133-134
R140 R142 R170 R173 R216-217 R225 R227
R255 R258 R292-293 R299 R301 R351-354
R365-368 R370-372 R376 R378-381
R451-454 R461-462 R469-472 R474-476
R479-480 R483-487 R494 R534 R552 R623
140-074-00 RESISTOR CF 1K1 5% R574-575
140-076-00 RESISTOR CF 1K3 5% R838
140-077-00 RESISTOR TF SMT 1K5 5% R548 R628
140-079-00 RES TF SM .1W 5% 1K8 OHM 1K8 5% R568 R572 R647 R650
140-080-00 RES TF SM .1W 5% 2K0 OHM 2K 5% R23 R103 R187 R265 R622 R747 R834 R837
140-083-00 RESISTOR TF SMT 2K7 5% R547 R627
140-084-00 RESISTOR TF SMT 3K0 5% R5-6 R9 R12 R80-81 R84 R87 R165-166
R169 R172 R250-251 R254 R257
140-085-00 RES TF SM .1W 5% 3K3 OHM 3K3 5% R691-692
140-086-00 RES TF SM .1W 5% 3K6 OHM 3K6 5% R327 R329 R421 R423
140-087-00 RESISTOR CF 3K9 5% R51 R61 R131 R141 R214 R226 R290 R300
R303 R382-384 R386 R488 R490-491 R836
140-088-00 RES TF SM .1W 5% 4.3K 4K3 5% R556-557 R636-637 R701-702 R766-767
055-241-00 REV A, Master board
241a
To Next Page
