Master Parts List CFX Assembly, 120v
Item#Part # Description Rev Qty Notes
090-120-00 CFX12 A3 A21 CFX12 ASSEMBLY
090-121-00 CFX16 A3 A21 CFX16 ASSEMBLY
090-122-00 CFX20 A3 A21 CFX20 ASSEMBLY
1 040-358-00 CBL RIB 18G 7P .156 16IN B 1
4 055-192-00-01 PCB ASSY LC EFTS-PWR MIX B1 A11
055-241-00-02 ASSY PCB CFX MASTER A A21
6 055-242-00-01 ASSY PCB CFX SLAVE 4 1 A11 (CFX12 has 1, CFX16 has 2, CFX20 has 3)
7 055-258-00-01 PCB ASSY PWR SPLY CFX A A11
8 055-260-00-01 PCB ASSY AC INPUT CFX A A11
9 080-142-00 SA XFMR -010 120V CFX12 A A11
2 080-144-00 SA BNC CFX 12/16/20 C1 A11
44 400-365-00 QDISK TAB .250 M #6 MNT A 1
11 410-005-00 INSL SILPAD TO-220 A 4
12 510-001-00 FUSE SB 1A 5X20MM 250V UL B 1
13 550-442-00 SCR CHASSIS TOP CXF 12 1 CFX12
13 550-443-00 SCR CHASSIS TOP CXF 16 A 1 CFX16
13 550-444-00 SCR CHASSIS TOP CXF 20 A 1 CFX20
14 550-445-00 CHASSIS BOTTOM CXF 12 A 1 CFX12
14 550-446-00 CHASSIS BOTTOM CXF 16 A 1 CFX16
14 550-447-00 CHASSIS BOTTOM CXF 20 A 1 CFX20
15 550-462-00 CLAMP TO-220 X 4 A 1
43 550-491-00 FAB PLT HTSK CFX PWR SPLY A 1
16 550-551-10 PNT LEFT SIDE CFX A 1
17 550-551-20 PNT RIGHT SIDE CFX A 1
18 550-552-00 SCR BACK CFX 12 B 1 CFX12
18 550-553-00 SCR BACK CFX-16 B 1 CFX16
18 550-554-00 SCR BACK CFX-20 B 1 CFX20
20 620-045-00 CBL FLT 14C W/PINS 3.5IN A 2
640-001-00 LC IEC SJT 10A/125V 6FT D 1 LINECORD
22 700-010-00 TF 6-32X1/4 PHP BLKZC A 26
23 700-011-00 MCH 4-40X1/4 BTNSKT BLKOX A 34
24 700-028-01 SEMS 6-32X5/16 PHP BLKZC B 6
25 700-028-03 SEMS 6-32X1/2 PHP BLKZC B 4
26 701-016-00 5-20X5/16 PHPII TYP B BLK A 23
27 705-001-00 KEPNUT 6-32 A 4
28 705-003-00 NUT HEX-SPLD W/400-214-00 A AR
29 705-008-00 NUT LOCK 8-32 A 2
31 710-002-00 WASHER-SPLD W/400-214-00 A AR
33 750-001-00 BUMPON ROUND BLK .63X.31 A 4
34 760-037-01 KNOB SLIDE 10X25MM MLDLIN A 11
35 760-037-03 KNOB SLIDE 11X24 BLUE A 4
36 760-048-01 KNOB 9MM LT GRY B 17
760-048-02 KNOB 9MM MAGENTA B 44
760-048-03 KNOB 9MM BLU/GRY B 34
39 760-048-04 KNOB 9MM DARK GRAY B 18
40 760-091-00 KNOB MASTER VOLUME A 1
41 780-050-00 LIPSEAL MASTER CFX A 1
42 780-051-00 LIPSEAL SLAVE 4 CFX A 1
790-002-00 BAG POLY 12 X 18 2MIL A 1
790-027-00 BAG POLY 20X7X36 4MIL GUS A 1
800-130-00 BOX CMPT CFX 12 B 1 CFX12
800-131-00 BOX CMPT CFX 16 B 1 CFX16
800-132-00 BOX CMPT CFX 20 B 1 CFX20
810-086-00 FOAM SET CFX 1
820-104-00 OWNR MNL COMPACT CFX A 1 COVERS ALL MODELS
