Mackie MDB-USB User Manual

Owner’s Manual
9
Owner’s Manual
MDB-USB Stereo Direct Box Block Diagram
USB
RECEIVER
FIXED RESISTANCE
FIXED RESISTANCE
5
4
6
MONO
OUTPUT LEVEL
LA
LINE AMP
LA
LINE AMP
2 3
1
XLR OUT L
PHONE JACK
HEADPHONE
2 3
1
XLR OUT R
FIXED RESISTANCE
FIXED RESISTANCE
LA
LINE AMP
LA
LINE AMP
5
4 6
GND
2
1 3
LEFT OUT
RIGHT OUT

Mackie MDB-USB Specifications

General

Best uses	Bass guitar, Digital piano, Guitar, Synthesizer
Product color	Black
Quantity	1
Frequency range	20 - 20000 Hz
Output impedance	600 Ω
Total Harmonic Distortion (THD)	0.01 %
XLR out	2
Power source type	DC

Weight and Dimensions

Depth	147 mm
Width	86 mm
Height	38 mm
Weight	500 g
