Mix Series Specifications:
Noise Characteristics
(20 Hz – 20 kHz bandwidth, 150 source impedance, EIN)
All outputs, master levels and channel levels off –100 dBu
All outputs, master levels unity, all channel levels off –90 dBu
All outputs, master levels unity, 1 channel level unity –85 dBu
Distortion (THD+N)
(20 Hz – 30 kHz bandwidth)
Mic Input to Main Output <0.25% @+4 dBu output
Attenuation / Crosstalk
(20 Hz–20 kHz bandwidth)
Inputs to Outputs @ 1 kHz –85 dB
Main Mix Off @ 1 kHz –75 dB
Frequency Response
Mic input to any output (gain @ unity) +0, –1 dB, 20 Hz to 30 kHz
Equivalent Input Noise (EIN)
(Mic in to Insert Send out, max gain.)
150 termination –125 dBu [Mix5, Mix8]
–122 dBu [Mix12FX]
Common Mode Rejection Ratio (CMRR)
(Mic in to Insert Send out, max gain.)
1 kHz better than –70 dB
Maximum Levels
Mic inputs (XLR) +19 dBu
Aux return in +16 dBu [Mix8]
All other inputs +21 dBu
All outputs +21 dBu
Impedances
Mic in 2 k [Mix5]
3.8 k [Mix8, Mix12FX]
All other inputs 10 k or greater
Tape out 1 k
Phones out 22
All other outputs 120 unbalanced,
240 balanced
EQ
High Shelving ±15 dB @ 12 kHz
Mid Peaking ±15 dB @ 2.5 kHz
Low Shelving ±15 dB @ 80 Hz
Low Cut Filter 18 dB/octave, –3 dB @ 80 Hz
AC Power Requirements
Power Connection 2-pin DC connector [US]
3-pin DC connector [EU]
Input 120 VAC, 60 Hz [US]
230 VAC, 50/60 Hz [EU]
Output 18 VAC, 600mA [Mix5, Mix8]
18 VAC, 1000mA [Mix12FX]
Operating Temperature 0˚ – 40˚C
32˚ – 104˚F
Physical Properties (product)
Mix5
Height 1.7 in / 43 mm
Width 5.5 in / 140 mm
Depth 7.7 in / 196 mm
Weight 1.4 lb / 0.6 kg
Mix8
Height 2.1 in / 53 mm
Width 7.8 in / 198 mm
Depth 9.6 in / 244 mm
Weight 2.5 lb / 1.1 kg
Mix12FX
Height 2.1 in / 53 mm
Width 11.7 in / 297 mm
Depth 9.6 in / 244 mm
Weight 3.7 lb / 1.7 kg

Mackie Mix8 Specifications

General

Microphone input impedance	3800 Ω
Frequency range	20 - 30000 Hz
Channels quantity	8 channels
DJ mixer	-
Product color	Black
Video capability	No
AUX in	Yes
Line inputs (RCA)	2
Equalizer bands quantity	3

Weight and Dimensions

Depth	244 mm
Width	198 mm
Height	53 mm
Weight	1100 g
Package depth	338 mm
Package width	231 mm
Package height	84 mm
Package weight	1400 g
