8/12 PAGES
Compact Mixers
PHANTOM
MIC IN
+48 VDC
LINE IN
LINE IN LEFT (MONO)
LINE IN RIGHT
AUX RETURN LEFT (MONO)
AUX RETURN RIGHT
PEAK
PEAK
MONO CHANNELS
1 and 2
GAIN
EQ
HIGHMID
80
12K2.5K
LOW
EQ
HIGHMID
80
12K2.5K
LOW
PAN
LEVEL
LEVEL
AUX
MAIN MIX
STEREO CHANNELS
AUX RETURNS
3/4 and 5/6
L
L
R
R
PAN
AUX
L
R
L
R
LEFT MAIN BUS
RIGHT MAIN BUS
AUX BUS
AUX SEND
HEADPHONE
OUTPUT
LEFT
RIGHT
METERS
TAPE TO CTRL RM/
PHONES
TAPE TO MIX
CONTROL
ROOM/
PHONES
LEFT MAIN
MIX OUT
RIGHT MAIN
MIX OUT
LEFT
CONTROL
ROOM
OUTPUTS
RIGHT
CD/TAPE OUT
LEFT
RIGHT
CD/TAPE IN
MASTER AUX SEND
LEVEL
Mix8 Block Diagram

Table of Contents

Other manuals for Mackie Mix8

Preview: Owner's Manual
Owner's Manual24 pages
Preview: Quick Start Guide
Quick Start Guide12 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mackie Mix8 and is the answer not in the manual?

Mackie Mix8 Specifications

General IconGeneral
Microphone input impedance3800 Ω
Frequency range20 - 30000 Hz
Channels quantity8 channels
DJ mixer-
Product colorBlack
Video capabilityNo
AUX inYes
Line inputs (RCA)2
Equalizer bands quantity3
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width198 mm
Height53 mm
Weight1100 g
Package depth338 mm
Package width231 mm
Package height84 mm
Package weight1400 g
