Maco HS Salamander evolution Drive 82 - Key and Abbreviations

12
Key and Abbreviations
Dimensions in [mm]: All dimensions without a unit denition are given in mm
O
!
HS Li and Slide element (LS)
FB Sash width (SW)
FH Sash height (SH)
RAB Frame outer width (FOW)
RAH Frame outer height (FRH)
Total length
GM Handle height (HH)
DM Backset drive gear (BS)
O Optional
Important Information
FE Fixed element
Permanently elastic sealant
