Maco HS Salamander evolution Drive 82 - Page 15

15
Hardware overview
1
HS handle
2
Li drive gear locks DM 37.5 PZ
3
Connecting rod punched HS 16.4 x 4
4
MACO GRP threshold with hinging groove
5
MACO Fiber-Therm roller track, 2.5 mm asymmetrical
6
MACO PVC intermediate prole
7
Gealan attachment rail for xed sash, length = 100 mm
8
Connection plate for Fibertherm Gealan S9000 silver
9
EPDM gasket for connection plate 2 mm
10
EPDM gasket for roller track groove 6 mm
11
Hardware screw Pozidrive 4 x 30 silver
12
Sealing plate with drainage for intermediate prole le silver
14
EPDM gasket for gasket plate 2 mm le + right black
15
EPDM gasket for buer stop bar xed sash Gealan S9000
16
EPDM gasket for intermediate prole Gealan S9000
17
EPDM gasket for centre area 2 mm black
18
EPDM seal Black for roller track at Gealan S9000
EPDM seal Black for roller track high Gealan S9000
19
Gasket bridge HS for 12 mm air
20
Front roller HS with brushes 300 kg silver
21
Rear roller HS with brushes 300 kg silver
22
Buer stop So 20 mm high grey
25
Packer for HS-PVC locking bolt, thickness = 0.5 + 1 mm silver
26
Rod guide for roller track high, groove 17 x 22
27
Countersunk screws B 4.8 x 80
28
Countersunk screws B 4.8 x 60
29
Countersunk screws B 4.8 x 38
31
Countersunk screws B 4.8 x 19
32
Countersunk screws B 4.8 x 90
optional
35
Stop buer package 28 mm gap
36
Countersunk self-tapping screws B 4.8 x 80
55
L&S roller underlay for front and back roller 10 mm stackable in silver
56
Rod guide for at roller track, silver, groove 27 x 22
57
Countersunk self-tapping screws B 4.8 x 25
58
Chip board screw PZ 5 x 30 countersunk
60
MACO Fiber-Therm snapper for at roller track
65
MACO Fiber-Therm doubling prole
