Macrom M-AN6560D User Manual

- 17 -
Specifications
General
Reference Supply Voltage ...........................................................................................................12V
Operating Voltage Range ...................................................................................................... 9 - 16V
Max Operating Current ....................................................................................................................15A
Grounding System Car Battery Negative Pole
FM
Signal Noise Ratio ....................................................................................................................
≥
55dB
Residual Noise Sensitivity (S/N=30dB) ...............................................................................
≤
10dBµV
Frequency Response (±3dB) ......................................................................................... 40Hz~12KHz
Station Seeking Level ........................................................................................................ 23±3dBµV
Distortion .................................................................................................................................
≤
1.0%
Stereo Separation (1KHz) ........................................................................................................
≥
25dB
Antenna Impedance ..................................................................................................................... 75
Ω
Frequency range .........................................................................................................87,5 /108,0MHz
AM
Residual Noise Sensitivity (S/N=20dB) ................................................................................
≤
28dBµV
Selectivity (±9KHz .....................................................................................................................
≥
50dB
Frequency range ............................................................................................................ 522/1620KHz
DAB
Residual Noise Sensitivity (RF=72dBM)...................................................................................... 60dB
Stereo Separation (1KHz)..........................................................................................................
≥
55dB
Frequency range............................................................................................................. 174 /240MHz
BT
Frequency ............................................................................................................... 2,402 - 2,480GHz
Power output
Frequency Response (±3dB .......................................................................................... 50Hz~16KHz
Maximum Output Power ......................................................................................................... 4×45W
Load Impedance ............................................................................................................................ 4
Ω
AUX IN
Distortion ..................................................................................................................................
≤
0.5%
Frequency Response (±3dB .......................................................................................... 50Hz~20KHz
Audio Input Level .................................................................................................................. 0.5Vrms
Audio
Audio Output Impedance ........................................................................................................... 100
Ω
Audio Output Level ......................................................................................................... 2Vrms(Max)
Video
Normal Video Input Level (CVBS ......................................................................................... 1.0±0.2V
Video Input Impedance ................................................................................................................ 75
Ω
Environment
Operating Temperature .............................................................................................. -20°C ~ +70°C
Storing Temperature .................................................................................................. -30°C ~ +80°C
Operating Humidity ........................................................................................................ 45%~80%RH
Storing Humidity ............................................................................................................ 30%~90%RH
