2
CONTENTS
PRECAUTION........................................................ 2
SPECIFICATION .................................................... 2
FRONT PANEL .......................................................3
REMOTE CONTROL .............................................. 4
BLUETOOTH OPERATION .................................. 5
MP4/MP5 OPERATION .......................................... 6
INSTALLATION ...................................................... 7
TROUBLE SHOOTING ........................................... 8
PRECAUTIONS
Use only in a 12-volt DC negative-ground electrical system.
Be sure to connect the color coded leads according to the
diagram.
Incorrect connections may cause the unit to malfunction or
damage the vehicles, electrical system.
Be sure to connect the speaker (-) leads to the speaker (-)
terminal.
Never connect the left and right channel speaker cables each
other or to the vehicle body.
Make sure all the connections are completely correct before
turning on your unit.
Using a fuse with a higher amperage rating may cause
serious damage to the unit.
DO NOT attempt to disassemble the unit.
Laser beams from the optical pick up are dangerous to the
eyes.
Do NOT block vents or radiator panels. Doing so many
cause heat to build up inside and may result in fire.
Make sure those pins or other foreign objects do not get
inside the unit; they may cause malfunctions, or create safety
hazards such as electrical shock or laser beam exposure.
Keep the volume at a level at which you can hear outside
warning sounds (horns sirens, etc.).
Stop the vehicle before carrying out any operation that could
interfere with your driving.
Do NOT work in extremely high or low temperature.
Be sure the temperature inside the vehicle is between +60℃
and -10℃ before turning on your unit.
SPECIFICATION
GENERAL
Power Supply Requirements
Chassis Dimensions
Bass (at 100 Hz)
Treble (at 10 kHz)
Maximum Output Power
Safety fuse
DC 12 Volts,
Negative Ground
178x 92x 50 mm
+ 10 dB / 10 dB
+ 10 dB / 10 dB
4 x 40W
15 Ampere (max.)
FM STEREO RADIO
Frequency Coverage
IF
Sensitivity(S/N=30dB)
Stereo Separation
87.5 to 108.0 Mhz
10.7 Mhz
10dB
30 dB
MW STEREO RADIO
Frequency Coverage
IF
Sensitivity(S/N=20dB)
522 to 1620 kHz
450 kHz
32 dBu
ACCESSORIES
Mounting Bracket(Half Sleeve)
Trim plate
Mounting Screw M5
Rubber
Release key
User manual
Wire connector
Remote control
1
1
1
1
2
1
1
1
Note:
Due to continuous product improvement, specifications and
design are subject to change without prior notice.
