Madas Technical Manual - 9|9.4 - REV. 0 of 8
th
Feb 2019MTC10
11.0 TRANSPORT, STORAGE AND DISPOSAL
• During transport the material needs to be handled with care, avoiding any impact or vibrations to the device;
• The transport and storage temperatures must observe the values provided on the rating plate;
• If the device is not installed immediately after delivery it must be correctly placed in storage in a dry and clean place;
• In damp facilities, it is necessary to use driers or heating to avoid condensation.
• At the end of its service life, the product must be disposed of in compliance with the legislation in force in the country where
this operation is performed.
12.0 WARRANTY
The warranty conditions agreed with the manufacturer at the time of the supply apply.
Damage caused by:
• Improper use of the device;
• Failure to observe the requirements described in this document;
• Failure to observe installation rules;
• Tampering, modification and use of non-original spare parts;
are not covered by the rights of the warranty or compensation for damage.
The warranty also excludes maintenance work, the assembly of devices of other manufacturers, making changes to the device
and natural wear.
13.0 RATING PLATE DATA
The rating plate data (see example provided here) includes the following:
• Manufacturer’s name/logo and address (possible distributor name/logo)
• Mod.: = device name/model
• WE (Working exit) = Output for operation
• FE (Fault exit) = Output for fault
• CE... = Certification pin number
• EN 1643 = Product reference regulation
• IP.... = Protection rating
• 230V.... = Power supply voltage, frequency (if Vac), followed by electrical absorption
• (-20...+60) °C = Temperature range within which product operation is guaranteed
• year = Year of manufacture
• Lot = Product serial number (see explanation below)
• U1802 = Lot issued in year 2018 in the 2
nd
week
• 1065 = progressive job order number for the specified year
• 00001 = progressive number referring to the quantity of the lot
Mod: MTC10
CE-0694/990100159 - EN 1643
IP65 – 230 V/50-60 Hz 3.2 VA
WE=2A - FE=1A
(-20...+60) °C
year: 2018 Lot: U1802 1065/00001
Valve test volume
Model Diameter
Valve volume
[dm
3
]
EVP... - EW... - EV...-1-3-6 DN 15
0.077
EVP... - EW... - EV...-1-3-6 DN 20
0.084
EVP... - EW... - EV...-1-3-6 DN 25
0.130
EVP... DN 32
0.630
EVP... DN 40
0.666
EVP... DN 50
0.944
EV...-1-3-6 DN 32-40-50
0.944
EVP... - EV...-1-3-6 DN 65
2.754
EVP... - EV...-1-3-6 DN 80
2.840
EVP... - EV...-1-3-6 DN 100
6.494
EVP... - EV...-1-3-6 DN 125
19.718
EVP... - EV...-1-3-6 DN 150
20.921
EVP... - EV...-1-3-6 DN 200
41.664
EVP... - EV...-1 DN 250
73.228
EVP... - EV...-1 DN 300
100.751
Pipe test volume
Diameter
Pipe volume
[dm
3
/m]
DN 15 - 1/2 0.20
DN 20 - 3/4 0.30
DN 25 - 1 0.50
DN 32 - 1 1/4 1.41
DN 40 - 1 1/2 1.83
DN 50 - 2 2.85
DN 65 4.55
DN 80 6.20
DN 100 9.00
DN 125 15.32
DN 150 22.24
DN 200 37.68
DN 250 58.51
DN 300 82.36
