Maestro E Series User Manual

P.7 Maestro E210 Series
3 PRODUCT FEATURES
3.1 General specification
Casing: Brushed Aluminum
Dimensions: 92x57x22(mm)
Weight: 150 g (approx.)
Operating temperature: -20 °C ~ +60 °C; up to 95 % R.H.
Storage temperature: -40 °C ~ +85 °C; up to 95 % R.H.
Flash memory (SPI): 32 MB
RAM (DDR2 SD-RAM): 128 MB
Ethernet LAN & WAN: 10/100BASE-T
Wi-Fi: IEEE 802.11b/g//n 2.4 GHz
GPS: IZatTM gen. 8C gpsOne
3.2 Power consumption (mA)
8V
12V
32V
E213
Idle (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module off)
165
110
43
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module idle)
265
171
65
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card connected, cellular module idle)
356
235
91
GPRS (2Tx,3Rx)@900/850MHz (PCL=5)
530
356
135
LTE in communication mode (Tx max.)
420
283
108
E214#358S#158
Idle (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module off)
118
79
30
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module idle)
145
99
38
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card connected, cellular module idle)
270
187
73
W-CDMA in communication mode (Tx max.)
575
386
146
LTE in communication mode (Tx max.)
695
471
179
E214G#00
Idle (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module off)
137
90
34
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card disconnected, cellular module idle)
195
135
51
Stand-by (WLAN, LAN, Wi-Fi, RS-232 & TF card connected, cellular module idle)
290
203
82
W-CDMA in communication mode (Tx max.)
650
445
170
LTE in communication mode (Tx max.)
730
495
193
