Chapter 1
Specifications
– Quad Band GSM 850/900/1800/1900MHz
– Support Data, SMS, Voice and Fax (Only M1002GAD)
– Max power output: 2W (850/900MHz), 1W (1800/1900MHz)
– Group 3 FAX support (Class 1 and 2)
– GPRS Class B class 10 (4Rx+1Tx or 3Rx+2Tx) at maximum speed
– SIM Tool Kit Class 2
– AT command set (GSM 07.05, GSM 07.07 and Sierra Wireless proprietary)
– Memory size: 64Mbits Flash and 16Mbits RAM
Power supply requirement:
– Input voltage range : 5-32V
– Rated current: 650mA
Typical current consumption:
@5V @12V @32V
GSM850/900 communication mode PCL=5 253mA 110mA 44mA
DCS1800 PCS1900 communication mode PCL=0 192mA 86mA 36mA
GPRS 850/900 2 Tx @ Gamma 3 438mA 175mA 70mA
GPRS1800/1900 2 Tx @ Gamma 3 282mA 125mA 50mA
Idle mode 50mA 29mA 13mA
Idle mode (RS232 not connected) 20mA 12mA 6mA
Interfaces:
– SIM Holder
– 15 pin sub-D connector
– 4 pin power supply connector
– SMA Cellular antenna connector (50Ω)
Dimensions:
– Overall size: 74.3mm x 60mm x 21.7mm
– Weight: 90g
Confidential, the whole document is the sole property of Maestro Wireless Solutions ltd. 9
