MAFI Trac T225 - Selecting higher or lower driving range

OPERATION
OPERATING PANEL FOR THE AUTOMATIC TRANSMISSION
Operating manual T225 / T230 65
Selecting higher or lower driving range
For unusual driving situations such as steep slopes, a lower
driving range can be selected in order to prevent an unwanted
shifting up of the transmission
On inclines on the other hand, shifting is possible again into
a higher driving range from a previously selected lower driving
range. Alternatively, shifting can be back to driving gear D.
Fig. 53: Driving ranges
X
Select the desired driving range by pressing the arrow keys.
Up arrow – higher driving program
Down arrow – lower driving program
The current driving range is displayed by the display on the
right side MONITOR.
The selected driving range is displayed by the display on the
left side SELECT.
The arrow keys can be activated during driving.
M
O
N
I
T
O
R
R
N
D
S
E
L
E
C
T
MODE
11-C25-067-084A-6
