Battery
Switch has an internal lithium-ion battery that
is rechargeable using the Switch charging/
data cable. Under normal training activities
with the backlight off, the battery should last
up to 8 hours. An optional Battery Extender
Pack is available as an accessory for Switch
which can give up to 16 hours of battery life.
Use of the backlight can help in making the
display more readable but is a drain on the
internal battery. The factory default for the
backlight is auto-off after 15 seconds but can
be changed in “Settings > Device Settings
> Backlight”. It is recommended that the
backlight not be set to be always on.
Charging the Battery
1. Place the charging/data cradle on the
back as shown.
Note: The above image shows the
battery charging/data cable being
attached to Switch without the Multisport
Mount. If you are using the Multisport
Mount, remove Switch from the mount
before attaching the charging/data cable.
2.
Connect the USB connector to a USB port
on a personal computer or AC power
adapter.
3. The charging screen is displayed.
4. Charge Switch completely to 100%.
Multisport Mounting
Disregard this section if you don’t have the
M
ulitisport Mount. The
M
ultisport Mount is
included with Switch Up and available as an
optional accessory for Switch.
The Multisport Mount provides a quick release
system with integrated wrist and bike mounts
for seamless transitions between sports.
Wrist Mount
1. Attach the wrist
mount around
your wrist.
2. Snap Switch into
the mount by
putting the bottom
of Switch in first
and then pushing
down on the top.
Bik
e Mount
1. Attach
the bike mount to your handlebars
or stem using the provided rubber rings.
2.
Snap Switch into the mount by putting
the bottom of Switch in first and then
pushing down on the top.
Handlebar Handlebar Stem
