Magic-Pro Computer MP-6VIP-C+ - JP4;JP5: CPU Host Clock Select; JP6: Bus Clock Select; JP10;JP11: USB Port Select; JVGA1: VGA Use

&
JVGA1: VGA Use
This jumper is set for the PCI VGA card only. Open this jumper when the system
is not able to boot up. If you use AGP card, it is important to set default with
JVGA1.
JVGA1
For PCI VGA card
Normal (default)
JP10 / JP11: USB Port Select
JP10 / JP11USB Port
Redirect USB port1 to USB
connector (default)
Redirect USB port1 to AGP
JP4 / JP5: CPU Host Clock Select
JP4 / JP5
CPU Host Clock
Auto (default)
!

!

JP4 JP5
100MHz (overlock)
!

!

JP4 JP5
100MHz
!

Auto Select 66/100/133MHz
(default)
!

133MHz
!

JP6: Bus Clock Select
Bus Clock Select JP6
