Model
Indoor Blower
Speed
Unit Voltage
(V)
0.1
" w.c.
0.2
" w.c.
0.3
" w.c.
0.4
" w.c.
0.5
" w.c.
EWC0512P12B
EWC0513P12A
TAP 1 (HEAT) * 208 or 230 615 590 570 545 525
TAP 2 (HEAT) 208 or 230 655 630 610 590 570
TAP 3 (HEAT) 208 or 230 795 780 760 745 725
TAP 4 (COOL) † 208 or 230 480 460 440 415 390
TAP 5 (COOL) 208 or 230 530 505 485 460 430
EWC0712P12B
EWC0713P12A
TAP 1 (HEAT) 208 or 230 615 590 570 545 525
TAP 2 (HEAT) * 208 or 230 655 630 610 590 570
TAP 3 (HEAT) 208 or 230 795 780 760 745 725
TAP 4 (COOL) † 208 or 230 480 460 440 415 390
TAP 5 (COOL) 208 or 230 530 505 485 460 430
EWC0512P18B
EWC0712P18B
EWC0513P18B
EWC0713P18B
TAP 1 (HEAT) 208 or 230 805 785 770 750 730
TAP 2 (HEAT) * 208 or 230 825 805 785 770 750
TAP 3 (HEAT) 208 or 230 910 890 875 860 845
TAP 4 (COOL) † 208 or 230 610 580 560 535 515
TAP 5 (COOL) 208 or 230 630 600 570 550 530
EWC1012P18B
EWC1013P18B
TAP 1 (HEAT) 208 or 230 805 785 770 750 730
TAP 2 (HEAT) 208 or 230 825 805 785 770 750
TAP 3 (HEAT) * 208 or 230 910 890 875 860 845
TAP 4 (COOL) † 208 or 230 610 580 560 535 515
TAP 5 (COOL) 208 or 230 630 600 570 550 530
EWC1012P24B
TAP 1 (HEAT) 208 or 230 805 785 770 750 730
TAP 2 (HEAT) 208 or 230 825 805 785 770 750
TAP 3 (HEAT) * 208 or 230 910 890 875 860 845
TAP 4 (COOL) † 208 or 230 770 750 730 710 690
TAP 5 (COOL) 208 or 230 820 790 770 750 730
EWC1512P24B
TAP 1 (HEAT) 208 or 230 805 785 770 750 730
TAP 2 (HEAT) 208 or 230 825 805 785 770 750
TAP 3 (HEAT) * 208 or 230 910 890 875 860 845
TAP 4 (COOL) † 208 or 230 770 750 730 710 690
TAP 5 (COOL) 208 or 230 820 790 770 750 730
EWC1012P30B
TAP 1 (HEAT) * 208 or 230 825 805 785 770 750
TAP 2 (HEAT) 208 or 230 910 890 875 860 845
TAP 3 (COOL) † 208 or 230 530 510 490 465 440
TAP 4 (COOL) 208 or 230 570 545 530 505 480
TAP 5 (COOL) † 208 or 230 950 920 900 885 865
EWC1512P30B
TAP 1 (HEAT) 208 or 230 825 805 785 770 750
TAP 2 (HEAT) * 208 or 230 910 890 875 860 845
TAP 3 (COOL) † 208 or 230 530 510 490 465 440
TAP 4 (COOL) 208 or 230 570 545 530 505 480
TAP 5 (COOL) † 208 or 230 950 920 900 885 865
NOTE: EWC**30B models shipped with Low and High stage Cooling taps connected for use of the two-stage system.
* As shipped speed for Heating operation
† As shipped speed for Cooling operation
Table 2. Supply Airow Performance (SCFM) as a Function of External Static Pressure
