Magner 175FF - Technical Specifications; Detection and Currency Capabilities; Performance and Counting Speed; Physical and Power Requirements

Magner175V/175FF USER Guide
Magner INT 52
11. Specification
Counterfeit
Detection
CIS, IR, MG, UV, FL
Pocket
Capacity
(New/Old)
Hopper
Over 500
Notes
Currency
Maximum 10 currencies
Reject
Pocket
100 Notes
High Speed
Value
counting
Count Only
1200
notes/min
Stacker
250 Notes
Value
1200
notes/min
Dimensions
300(W) x 321(D) x 310(H) mm
Fitness(Magner175FF)
1200
notes/min
Weight
Net: 14 Kg, Gross: 16 Kg
Serial(option)
1000
notes/min
Power Supply
100 ~ 240V AC, 50/60 Hz
Fitness
Stains, Limpness, Dog-ears, Tears,
Holes, Folds, Mutilations, Thickness
Repairs, Composed, De-inked, etc.
Globalization
Local language support,
software customizing
Communication
Channel
LAN, USB, RS232C (External
Display, Thermal Printer)
User
Interface
Colors TFT-LCD(4.3 inch), Audio
Upgrade
LAN, USB
