3 DEVICE DESCRIPTION
3.1 INTENDED PURPOSE
CLIMA-TECH TOP is a fully automatic device designed for automotive air-conditioning
installation maintenance.
Recovery, recycling, emptying, oil injection, UV additive injection, installation charging
and washing are the functions which can be performed by CLIMA-TECH TOP in a
completely safe way and with maximum efficiency, exceptional in other similar
equipment.
The device was not designed for disposal! (see Glossary section)
3.2 Description and layout of components
This device consists of several assemblies installed inside the housing and accessible only
after the front and top covers (fixed with screws) are removed, and of several assemblies
installed outside and presented in the figure below.
