What to do if the pump will not start or stop on a Magnetrol Switch?
If the pump associated with your Magnetrol Switch isn't starting or stopping, examine these external factors: ensure that fuses are intact, reset any tripped reset buttons, verify the power switch is on, check for any issues with the controlled equipment, and inspect the wiring leading to the control for defects.
What to do if float isn't buoyant in liquid in Magnetrol Switch?
If the float in your Magnetrol Switch isn't buoyant in the liquid, verify that the float is indeed buoyant. If the float is filled with liquid or has collapsed, replace it immediately.
General| Model | G3F-300 |
|---|---|
| Electrical Rating | Up to 15A @ 125/250 VAC |
| Enclosure Rating | NEMA 4X, IP66 |
| Output Type | SPDT |
| Power Supply | Not applicable (purely mechanical) |
| Material | 316 Stainless Steel |
| Specific Gravity | 0.4 minimum |
Explains the magnetic field principle of operation for float-operated switches.
Describes the operational sequence during liquid level changes.
Recommendations for critical alarm system setup.
Guidelines for proper piping arrangement and support.
Instructions for correct vertical mounting of the switch.
Steps and precautions for connecting electrical wiring.
Adjusting differential for low level switch trip points.
Adjusting differential for high level switch trip points.
Periodic inspections and tests every six months.
Periodic inspections and tests every twelve months.
Diagnosing and resolving operational problems.
Actions and practices to avoid for proper operation.
Lists safety and regulatory certifications for the switches.
Dimensional data and specifications for sealed cage models.
Dimensional data and specifications for flanged cage models.
Details actuating levels, steam ratings, and specific gravities.
