General| Type | Level Switch |
|---|---|
| Process Connection | Threaded or flanged |
| Material | 316 stainless steel, Hastelloy C, or other alloys |
| Electrical Rating | SPDT or DPDT contacts, various voltage options |
| Application | Liquid level detection |
| Mounting | Top or side mounting |
| Housing Material | Aluminum or Stainless Steel |
| Operating Temperature | -40°C to 150°C (-40°F to 302°F) |
| Approvals | ATEX, IECEx, CSA, FM |
Provides initial setup and calibration overview for the Thermatel switch.
Covers unpacking, handling, and initial installation steps for the device.
Safety procedures for handling static-sensitive electronic components.
Detailed steps for making electrical connections to the TD1 and TD2 units.
Configuring internal settings and parameters based on application.
Recommended switch positions for various operational modes.
Steps to calibrate the unit for specific level or flow applications.
Calibrating the switch for level detection applications.
Calibrating the switch for flow detection applications.
Information on device diagnostics, fault indication, and problem-solving.
How the unit identifies and reports operational faults.
Common issues and recommended solutions for operational problems.
Technical performance data including voltage, power, and temperature ratings.
Details on warranty coverage and service terms.
