A. Getting To Know Your Camera
Below are three views of the MAGPiX B350 to help familiarize
you with your new camera. The parts and corresponding
numbers will be referred to throughout this manual.
1 Left Barrel
2 Left Objective Lens
3 Camera Lens
4 Right Objective Lens
5 Right Barrel
6 Dioptric Knob
7 Right Eyepiece
8 Shutter/Select Button
9 USB Port
10 Power/Mode Button
11 Left Eyepiece
12 Focus Knob
13 LCD Display
Figure 1. Top View
