Appendix A - Technical Specifications
eDynamo| Secure Card Reader Authenticator | Installation and Operation Manual
Page 32 of 34 (D998200110-23)
Appendix A Technical Specifications
eDynamo Technical Specifications
Reference Standards and Certifications
Magnetic stripe: 3 Track Read Data
Identification Cards Financial Transaction Cards (ISO 7813)
AAMVA
Identification Cards Integrated Circuits with Contacts (ISO 7816)
EMV ICC Specifications for Payment Systems Ver 4.3, L1 Contact and L2 Contact
Encryption: TDEA (3DES)-CBC using DUKPT
IPC-A-610 Class II Assembly
Ingress Protection: IP-30 per ANSI/IEC 60529-2004
FCC Title 47 Part 15 Class B
CE Level B EMC
CE Safety
UR/CUR UL Recognized
California Proposition 65 (California)
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specification 2.0
TQM Label Certified
Physical Characteristics
Dimensions (L x W x H):
2.45 in. x 1.52 in. x 0.97 in. (62.2 mm x 38.7 mm x 24.7 mm)
Weight
Handheld: 2.2 oz. (60 g)
With docking station: 4.3 oz. (120 g)
Supported Mounting Options:
Handheld
Countertop with optional docking station micro-suction pads
Card Read Characteristics
Magnetic Stripe Reader:
Bidirectional 3 track non-encrypting IntelliHead magnetic stripe reader
(MSR) with MagnePrint
Magnetic Stripe Decoding:
Financial (ISO Type B), AAMVA, or Other
Acceptable Swipe Speeds:
6 inches per second to 60 inches per second
Chip Card Reader:
EMVCo L1 and L2 Contact Reader
User Interface Characteristics
Status Indicators:
General Status LED (Red/Green/Amber)
Bluetooth Status LED (Blue)
Display Type:
Not Applicable
Display Size (viewable area):
Not Applicable
Display Resolution:
Not Applicable
