1. Bring the vehicle to a complete stop
2. Brake pedal depressed
3. Shift the gear lever into neutral
4. Turn the four wheel drive selector switch to the 4H position. The 4WD LOW
lamp in the cluster goes OFF and the 4WD HIGH lamp should illuminate. If the
4WD LOW lamp doesn't go out within 10 sec, drive forward or reverse for a
short distance, stop the vehicle completely, shift the gear lever into neutral
and operate the selector switch knob again. If the problem persists contact an
Authorized Mahindra Dealer as soon as possible. There may be a malfunction
in the four wheel drive system
Note that both the lamps will illuminate during shifting.
11.8.2 2WD/4WD Lamps - Instrument Cluster
4WD LOW Lamp
This lamp alerts the driver that the vehicle is in the 4L (four wheel
drive low mode). The 4WD LOW lamp illuminates in the cluster
when the transfer case has shifted to the 4L mode. If the lamp
fails to illuminate when the ignition is switched ON, or the lamp
continuously remains ON even if the switch is not in the 4L position, then have the
system checked by an Authorized Mahindra Dealer.
4WD HIGH Mode Lamp
This lamp alerts the driver that the vehicle is in the 4H (four wheel
drive high mode). The 4WD HIGH lamp illuminates in the cluster
when the transfer case has shifted to the 4WD HIGH mode. If the
lamp fails to illuminate when the ignition is switched ON or the
lamp continuously remains ON even if the switch is not in the 4H position, then have
the system checked by an Authorized Mahindra Dealer.
In case of any malfunction in the transfer case, both 4WD HIGH and 4WD LOW
mode lamps illuminate at the same time. The vehicle should be taken to an
Authorized Mahindra Dealer immediately.
Situations when both lamps will illuminate at the same time, but it is not a concern;
• Ignition ‘ON’ initial blink
• When shifting from 4H to 4L
• When shifting from 4L to 4H
STARTING AND DRIVING THE VEHICLE
