8-5
8.4 Tip-Tap ORVM Adjustment (if equipped)
W12H08
Tip Tap ORVM’s can be adjusted by hand in the direction as indicated by the arrows.
Adjust the mirror as required to bring the rear traffic vision as desired.
8.5 Manual (Joystick) ORVM Adjustment (if equipped)
W12H09
Manual ORVM’s can be adjusted by the joystick provided on the ORVM trim. Adjust
the joy stick as required to bring the rear traffic vision as desired.
8.6 Electric ORVM Adjustment (if equipped)
The electric exterior mirror adjustment switch is located on the instrument panel on
the RHS of the driver adjacent to the head lamp levelling switch. The joystick on the
switch can be used to select the left/right mirror and also to adjust the respective
mirror.
L
O
R
W12H10
8.7 Interior Mirror
W12H11
FEATURES AND CONTROL
