A
Front Passenger Window Switch
D
Power Window Lock Switch (Child
Safety)
B
Driver Door Window Switch
(Auto)
E Rear LH Window Switch
C Rear RH Window Switch
The quadruple switch controls the window winding functions of all the doors of the
vehicle. It also houses a child safety switch that enables/disables the power window
operation of both the rear doors when operated independently from the respective
door. Power windows can be operated only when the ignition is “IGN” position. The
quadruple power window switch is located on the driver door trim / floor console
depending on the variant. Passengers can also raise or lower their respective
window glasses individually by the separate switches provided on each of the door
trim pads.
