4. Cut the rubber bulb and attach the TTV tool to the valve. Remove the valve
from the rim by pulling through the rim, or simply pull through without cutting
the bulb
5. Lift the outer tyre bead over the rim using a tyre tool
The valve must be positioned just left of the start position to avoid sensor
damage. Do not touch the sensor with the tyre tool.
6. Lift the inner tyre bead over the rim using the tyre tool
7. Remove existing valve stem
Starting to mount the tyre from the valve location is a wrong fitment. Fixing
tool/stem may hit the sensor and damage it. Start from the opposite direction.
12.6.5 Functionalities of TPMS System
• Low Pressure Monitoring
• High Pressure Monitoring
• High Temperature Monitoring
• Pressure Leakage Monitoring
• Spare Tyre Swap
• Sensor Signal Missing (Communication error)
• TPMS Sensor Faulty.
Low Pressure Monitoring
Low pressure monitoring is to indicate low tyre pressure. Please note the following
points.
• Low pressure alert will be set only when the tyre pressure value goes below 24
psi
• Low pressure alert in the main alert screen will pop up once for driver notification
when the alert is set and the vehicle is in running condition. Otherwise the alert
will remain in the information screen and alert register screen
• If low pressure is observed, respective tyre should be rectified with cause of low
pressure and then fill air
• Once low pressure alert is set with tyre pressure lower than 24 psi then the alert
shall not be cleared until the pressure is filled more than 28 psi
WHEELS AND TYRES
