© Copyright Mahindra & Mahindra Ltd. 082014
4-5
Symbol Warning Lamp/Tell Tale Lamp Pre-check Lamp Status Action/Remarks
Parking Brake ON/Brake Fluid Low
Warning Lamp
Yes
Continuously ON
Either one of below conditions:-
1) Park brake might be engaged
2) Brake fluid level might be low
Contact Authorized Mahindra Dealer immediately for assistance if the lamp is not
turning OFF even after checking the above conditions
Left Turn Indicators No
Slow or Fast Blinking
Indicates left turn lamp is blinking
Slow Blinking: Normal operation
Fast Blinking: One /more left turn lamp bulb has fused. Have the bulb replaced
Water in Fuel Filter Warning Lamp
Yes
Continuously ON
Indicates water in fuel filter. Drain the water from filter or contact an Authorized
Mahindra Dealer for assistance
Security Lamp
No
Slow or Fast Blinking
Slow Blinking: Vehicle armed and Immobilizer system active
Fast Blinking: Once the ignition is turned OFF, security lamp will blink at fast rate
frequency indicating vehicle is secured against unauthorized start of engine
Check Engine Lamp
For about 3 sec
Continuously ON or Blinking
There is a potential malfunction in the engine system, contact an Authorized
Mahindra Dealer immediately
High Coolant Temperature Warning Lamp
No
Continuously ON or Blinking
Engine temperature very high. Contact an Authorized Mahindra Dealer
immediately
INSTRUMENT CLUSTER OVERVIEW
