Mahindra 35 Series User Manual

E-27
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Removal of Rear Axle
7. Sling the rear axle securely with a suitable hoist,
tension the sling.
8. Remove securing bolts (A) of Rear Axle Housing.
9. Ease the axle away from transmission-case.
NOTE: Removal / Assembling of LH / RH axle are
same.
3. Dismantling
1. Remove the bolt, shims and lock plate and
washers (as shown in fig.).
2. Remove bull gear (B).
3. Tap the rear axle splined end with copper hammer
and pull out the rear axle from other end.
Rear Axle

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
