E-29
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Rear Axle
5. Assembly
1. Install big end ball bearing in Real Axle Carrier
(RAC) and lock with circlip (H).
2. Clean retainer surface area and fit new oil seal
in retainer Rear Axle (2 nos.).
3. Install oil seals with retainer in Rear Axle.
4. Install outer ball bearing with fixture for
positioning of bearing.
5. Apply liquid gasket on retainer.

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
