Mahindra 35 Series User Manual

E-48
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Differential Lock System
2. Removal
a. Remove Differential lock arrangement as per the
procedure given in differential section.
b. Remove differential lock pedal shaft (A) by
removing spring pin (B).
c. Use Special Tool (C) to remove spring pin.
d. Remove fork spring lock pin (D).
e. Hold spring and differential lock fork and pull
differential cross shaft from RH side.
Removal of Differential Lock Shaft Pin
Removal of Differential Lock Shaft
Special Tool

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
