F-8
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Front Axle
Sr. Location Size / Min. Torque Max. Torque
No. Description (N-m) (N-m)
1 A. Top Cover LH
B. Top Cover RH
C. Turning Arrest Rear Side Nut M12 100 110
2 Swivel Housing LH & RH Stud M12 55 62
3 A. Swivel Housing LH & RH Drain Plug ½” NPSF 30 40
B. Beam Housing
4 Pillow Block Front & Rear Grease Nipple 1/8” NPSF 20 25
5 Housing Input Shaft To Housing Bolt M12 x 1.5 x 30 115 125
Differential Carrier
6 Housing Differential Carrier To BOLT M12 x 1.75 x 35 110 120
Beam Housing
7 Bearing Carrier To Housing BOLT M10 x 30 40 50
Differential Carrier
8 Differential case To Ring Gear BOLT 7/16-20 UNF, 85 90 100
9 Differential case To Ring Gear BOLT 7/16-20 UNF, 23 90 100
10 Pillow Block Front To Beam Housing NUT M16 60 70
11 Swivel Housing Allen Bolt M8 x 1.25 x 16 25 35
12 Beam Housing To Front Axle Spacer Hex Bolt 1/2’ - 20 UNF x 120 100 110
To Side Housing For 33 To 43 PTO
13 Beam Housing To Front Axle Spacer Hex Bolt 1/2’ - 20 UNF x 35 100 110
To Side Housing For 29 PTO
14 Cover Swivel Housing Bottom Bolt M10 x 20 62 72
To Swivel Housing
15 Retainer Spindle Axle To Spindle Axle Bolt M10 x 1.25 x 28 62 72
16 Hub Housing To Swivel Housing Bolt M10 x 30 40 50
17 Top Cover To Swivel Housing Bolt M12 x 50 70 80
18 Retainer Bearing Hub Housing Bolt M8 x 20 20 25
To Hub Housing
19 Power Cylinder To Beam Housing Bolt M14 x 1.5 x 33 130 150
20 Tie Rod Ball Joint Assembly Bolt M18 x 1 Nylock nut 140 160
To Top Cover
3. TORQUE CHART
