F-17

35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08

Front Axle

D. ASSEMBLY OF HUB/SWIVEL/SIDE HOUSING

6. Lift the side housing and fit to swivel housing

by slight tapping.

7. Press oil seal (F) inside top cover (G).

8. Fit top cover to side housing by slight tapping

and tighten the mounting bolt to specified

torque (70-80 Nm) and tighten the nut to

torque 110 Nm.
