F-21
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
F. DIFFERENTIAL GROUP RING GEAR ASSEMBLY
7. Locate ring gear (J) on RH Differential case.
8. Put bolt along with lock washer and torque the
bolt to 100 Nm.
9. Lock the bolts with washer by bending it on bolt
head.
10. Fit the taper roller bearing (K) (temp 120ºC) on
LH differential case.
11. Fit the cone (L) into bearing carrier (M) with taper
roller bearing (N).
NOTE: The taper roller bearings and cups / cones
are not serviceable separately.
Ensure to assemble new match pair while
repairing.
12. Hold the housing differential carrier (O) on
suitable fixture and place differential assembly.
Front Axle

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
