Mahindra 700624-2 - Maintenance; Adjustments; Lubrication; Shear Bolt Replacement

12
MAINTENANCE
MAINTENANCE
ADJUSTMENTS
Skidshoeadjustment:
LEVELPAVEDSURFACE:Adjustskidshoestoallow
3/16" to 1/4" or 5mm to 7mm clearance between
cuttingedgeandsurface.
UNEVENORGRAVELSURFACE:Adjustskidshoes
to allow 1/2" to 5/8" or 13mm to 16mm clearance
betweencuttingedgeandsurface.
CUTTINGEDGEMAINTENANCE
Verify from time to time the wearing on the cutting
edgeto make sureyou do not wearoutthe base of
the snowblower’s chassis. This cutting edge is
reversible.
WARNING
TOPREVENTINJURIES:
Stopthevehicle’smotor.
Applyparkingbrake.
Removetheignitionkey.
AUGERS AND FAN SHEAR BOLT
REPLACEMENT
Shear bolts are to be considered a preventive
measure and not an assured protection. Operator
vigilanceisrequired.Thoroughly inspecttheareas
wherethesnowbloweristobeusedandremoveall
foreignobjects.
Toavoiddamagetothesnowblower:
Useonlytheoriginalshearbolts.
#106443inbagsof10fortheaugers.
#105627inbagsof10forthefan.
The use of any other shear bolt will not insure any
protectionandmayvoidthewarranty.
IMPORTANT:ITISVERYIMPORTANTTOREPLACE
THEAUGERSINTHESAMEPOSITIONASSHOWN
IN THE DRAWING BEFORE INSTALLING THE
SHEARBOLTS.
MAINTENANCE
Check mounting bolts at frequent intervals for proper
tightness inorderto preventcostlyrepairs. Make sure
yoursnowblowerisinsafeworkingcondition.
LUBRICATION
Driveline;
Every16hoursofuseandbeforestoringattheendof
theseason.
Gearbox:
Change the oil after the first 100 hours of use. Then
changeafterevery2500hoursorevery6months.
Thetypeofoilused:S.A.E.grade80W90.
Thegearboxshouldhaveatotalof500mlofoilorfilled
abovetheoutputshaft(seefigure).
Greasablebearings:
Greaseevery16hoursofuse.
Grease
fitting
Oilfitting
