DISMOUNTING&STORAGE
ATTENTION:Alwaysinstalltheprotectivecoverson
theendsofthehydraulichoseswhentheare
disconnected.Thisistopreventanypollutantsfrom
enteringthevehicle'saccessory’shydraulicsystem.
ATTENTION:Cleanupalloilspillstoprevent
accidents.
WARNING
TOPREVENTINJURIES:
Parkthevehicleonaflatsurfaceinawellventilated
area.
DisengagetheP.T.O.
Applyparkingbrake.
Wait until all moving parts have stopped before
leavingthedriver’sseat.
Usewheelchocks.
Lifttheaccessoryandstoptheengine
SNOWBLOWERDISMOUNTING
1) Unplugthehydraulichosesforthechuterotationand
wrapthemaroundthesnowblowerchute.
2) Removethehalfdrivelinefromtheshaft.
IMPORTANT: Ifthisstepisnotdone,itwillcause
damagestopartsofthedrivemechanismortothe
subframe.
3) Lowertheparkingstand.
4) Remove the pins (item 1) and put them in the
holes (item 2) on the upper lift arm and secure
theminplacewiththelynchpins(item3).
5) Lowertheaccessory.
SUBFRAMEDISMOUNTING
WARNING
TOPREVENTINJURIES:
Parkthevehicleonaflatsurfaceinawellventilated
area.
DisengagetheP.T.O.
Applyparkingbrake.
Wait until all moving parts have stopped before
leavingthedriver’sseat.
Usewheelchocks.
Lifttheaccessoryandstoptheengine.
Thenextsteprequiresthevehicle’shydraulicsystem.
Beawarethatthevehicleisstillrunning.
IMPORTANT:Whenthereisanaccessoryinstalled
onthevehicle,itisnotrecommendedtousethis
methodifthereisnotenoughgroundclearanceto
slidethesubframefromunderneaththevehicle.
Subframewithsnowblower:
1) Unplugthehydraulichosesforthechuterotationand
wrapthemaroundthesnowblowerchute.
2) Raisethesnowblower.
3) Removetherearpinthatunitestherearsubframeto
therearhitch.
4) Lowerthesnowblower.
ATTENTION:therearpartofthesubframewilllower
totheground.
5) RemovethedriveshaftfromthemidPTO.
NOTE:Thisstepisimportanttoavoiddamagesto
thedrivemechanismortothevehicle.
6) Removetherearhitch(optional).
7) Removethefrontpinfromthesubframe.
8) Activatethehydrauliccylindertolowerthefront
partofthesubframe.
9) Unplugthehydraulichosesfortheliftmechanism
andremovefromtheirsupports.
10)Backupwiththevehicletofreethesubframe.
Subframewithoutsnowblower:
1. Removetherearpinthatunitestherearsubframe
totherearhitch.
2. Putablockofwoodundertheliftarms.
3. Lowertheliftarmsontheblockofwood.
4. Removethefrontpinfromthefronthitchsupport.
6. Activatethehydrauliccylindertolowerthefront
partofthesubframe.
7. Unplugthehydraulichosesfortheliftmechanism
andremovefromtheirsupports.
8. Backupwiththevehicletofreethesubframe.
ENDOFSEASONSTORAGE
a) Clean snowblower and subframe thoroughly and
repaintallpartsfromwhichpainthasworn.
b) List the replacement parts that will be needed for
thenextseason.
c) Storethesnowblowerandthesubframeinadry
place.
d) FollowtheinstructionsintheLubricationsection.
