Maico MA 42 Service Manual

Service Manual MA 42
D-0125965 Rev. D
38
18/05/2022
DEVICE SPECIFICATIONS
Power supply
UES24LCP-
120200SPA
Consumption
Approximately 24 W
Input
100-240 VAC ± 10 %, 50/60 Hz, 0.5 A
Output
12.0 VDC/ 2.0 A
Dimensions
Max. 88 mm x 30 mm x 57 mm
3.46” x 1.18” x 2.24”
Mode of Operation
Continuous
Battery
Primary lithium coin cell battery (CR2032 type) used for the
internal real time clock system
Environmental
conditions:
Operation:
+15 °C - +35 °C / +59 °F - +95 °F
Humidity: 30 % - 90 %, non-condensing
Storage:
0 °C - +50 °C / +32 °F - +122 °F
Humidity: 10 % - 95 %, non-condensing
Transport:
-20 °C - +50 °C / -4 °F - +122 °F
Humidity: 10 % - 95 %, non-condensing
Ambient
pressure:
98kPa - 104 kPa
Altitude rating
Max operating altitude 2000 m / 6561 ft above sea level
Weight
1.5 kg/2.7 lbs
Dimensions
W x D x H: 34.5 x 20 x 8 cm / 13.4” x 7.9” x 3.2”
Display
5.7”, TFT display, 640 x 480
User Interface
Keys, control dials
Language Settings
Chinese, German, English, Spanish, French, Polish, Turkish,
Russian, Japanese
Monitor
Build in monitor speaker, headset
Warm-up Time
Less than 1 min after power on (incl. boot-up time)
Communication
Talk forward and talk back
Stimulus Functions
Tone Presenter/Interrupter
Lock (tone presentation of both channels simultaneously)
Track (fixed level difference between both channels)
Masking
Data Interfaces
PC Connection
USB
Printer Connection
USB
External Devices
Audio device, USB Thermal Printer
Supported Printers
HPRT HM-E300
PC Connection
USB: the system cannot be operated from a PC.
Using MAICO Sessions together with the OtoAccess
Database, Noah or a Practice Management Software via
BDT/GDT-interface (only for Germany, Austria and
Switzerland), data can be transferred and saved on the PC.
