Maico MA 42 Service Manual

Service Manual MA 42
D-0125965 Rev. D
3
18/05/2022
MA 42 Control Panel
2.1 Display and Control Panel
The main functions of the MA 42 are directly accessible by using the function keys which
are located around the display.
Some of the function keys behave differently depending on how long they are pressed:
Quick Select
Press briefly
Selects directly
e.g.
Advanced Select
Press and hold for 2 s
opens selection menu
with all options shown
e.g.
Figure 1 and 2 show the Display and the Control Panel of the MA42.
NOTE: Buttons that have a filled arrow displayed (i.e., ▲, ►), indicate Advanced Select
is available.
Figure 1
