Maico PILOT TEST User Manual

Operation Manual PILOT TEST
8504660 Rev. 3
17
06/11/2019
5.1.4 Display and Control Panel
Figure 4 shows the Display and the Control Panel of the PILOT TEST.
Figure 4
Table 7 Explanation of Keys
KEY
EXPLANATION
KEY
EXPLANATION
Group
Selection of the word list for
PILOT TEST (Group 1-4)
Menu
Set up Menu (see Section 7 of
Operating Instructions)
Start / Stop
Start / Stop of PILOT TEST
Enter
Store response during test
Pause
Temporily stop PILOT TEST
Audiometer
Starts Tone Audiometry
Forward
PILOT TEST: Next word
Audiometry: Pulse tone on
Loudness
Decrease or increase of
intensity level (dB) in Tone
Audiometry mode
Backwards
PILOT TEST: Repeat last word
Audiometry: Pulse tone off
Frequency
Decrease or increase of
frequency (Hz) in audiometry
mode
L / R Ear
Change ear selection
Tone
Signal presentation in Tone
Audiometry test (adjustable in
the User menu)
