2. Product information │ uk
23
2.3 Controls, sensors
RLS
1
WR
RLS 1 WR
room air control
for
● standard unit
● comfort unit
Optional for
● bypass unit
With step switch and
filter monitoring.
Operating modes:
Humidity protection,
ventilation
level 1, 2 or 3.
RLS
D1
WR
RLS D1 WR
room air control
for
● bypass unit
Optional for
● standard unit
● comfort unit
Operation manual
(ventilation levels)
or with automatic
time program
P1 or P2.
Parameters:
switching times,
summer function,
bypass parameter.
SKD
CO
2
sensor
(optional)
Records the carbon
dioxide content
"CO
2
". The supply of
fresh air depends on
the level of CO
2
in the
room.
EAQ
10/2
Air quality con-
troller (VOC)
Controls the unit in
terms of air quality.
HY 5
Hygrostat
(optional)
Records the relative
air humidity. The
supply of fresh air
depends on the level
of relative humidity in
the room.
2.4 Intended use
● The WS 170 is used as a ventilation unit
with heat recovery system that provides
controlled ventilation of apartments, offices
or comparable rooms.
● The ventilation unit is only intended for
domestic use and similar purposes.
● The ventilation unit is only intended for
permanent installation in buildings. It may
only be fitted on walls with sufficient load-
bearing capacity.
● The WS 170 may only be used in line with
the calculations/designs carried out by the
engineering office.
2.5 Foreseeable cases of misuse
Maico is not liable for damages caused by
use contrary to the intended purpose. Under
no circumstances should the unit be
used:
● during the building phase.
● in high levels of dust.
● close to flammable materials, liquids or
gases.
● to convey chemicals, aggressive gases
or vapours.
● In potentially explosive atmospheres.
● in swimming pools.
● to dry out new buildings.
● in combination with laboratory extractors.
● in combination with extractor hoods, that
are connected directly to the controlled
domestic ventilation exhaust air channel.
For energy-usage reasons, we
recommend using extractor hoods in
circulating air mode.
3. Safety instructions
3.1 General
● Ask your installer to familia-
rise you with the ventilation
unit and the room air control
once the installation is
complete.
● This fan unit can be used by
children aged 8 and above,
and by people with reduced
physical, sensory or mental
capabilities or by persons with
insufficient experience or
knowledge provided they
