9. Spare parts uk
37
Important for orders
When ordering spare parts,
state the article number as well as
the unit type and serial number of
the ventilation unit.
Item
Designation
Article no.
1
Plug connector with
lip seal SVR 125
(1 item)
0055.0183
2
Pipe elbow
B90-125 (1 item)
0055.0312
3
Wall bracket
0018.1076.0000
4
Single cable screw
connection
0192.0585.0000
5
7-way cable duct
0192.0586.0000
6
Unit switch
0157.1178.0000
7
RLS 1 WR
room air control
0157.0809
8
RLS D1 WR
room air control
0157.0828
9
Door contact switch
0157.1150.0000
10
Additional circuit
board
E101.1356.0000
11
WR control circuit
board
0101.1352.0004
12
Condensate elbow
with reducer
0093.1247.9000
13
Fan
0156.0127.0100
14
Temperature
sensor with
grommet
0157.0833
15
Actuator drive
for bypass
0157.1177.0000
16
Bypass shutter
compl.:
Right-hand version
Left-hand version
0018.1089.9000
0018.1100.9000
17
Frost protection
heating
0157.1187.0000
18
Frost protection
heating cover grille
0150.0336.0000
In case of questions
Maico Elektroapparate-Fabrik GmbH
Steinbeisstrasse 20
78056 Villingen-Schwenningen, Germany
Tel. +49 7720 694 445, Fax +49 7720 694 175
E-mail: ersatzteilservice@maico.de
Item
Designation
Article no.
19
19.1
19.2
F7 filter:
1x WSF 170
pollen filter,
class F7
Alternatively:
1x WSF-AKF 170
active carbon
air filter, class F7
0093.0271
0093.0272
20
10x WSG 170
air filter, class G4
0093.0270
21
Push-in frame for
G4 filter
0093.0269
22
Heat exchanger:
Right-hand version
Left-hand version
E192.0570.9000
E192.0570.9100
23
Front cover
for standard unit:
Right-hand version
Left-hand version
E018.1077.9000
E018.1077.9100
Front cover
for comfort unit:
Right-hand version
Left-hand version
E018.1078.9000
E018.1078.9100
24
Front cover for
bypass unit (with
bypass channel):
Right-hand version
Left-hand version
E018.1079.9000
E018.1079.9100
